PHOTO GALLERY
Special specification. Max. working width is 1400mm ( 55" ).
Two sets of auto feed-in & two sets of auto output system make planing smoother and stabler.
Tough and heavy structure makes the machine maintain it's life & stability even for heavy duty planing.
6” double-holes lifting dust hood inside & outside.
Three sets of table rollers. ( Two sets of motive power rollers )
CUTTER
4T Plane cutter
Standard
4T Spiral cutter (14x14x2.0)
Optional
4T Spiral cutter (15x15x2.5)
Optional
6T Spiral cutter (14x14x2.0)
Optional
6T Spiral cutter (15x15x2.5)
Optional
4T Heavy duty spiral cutter (1.5x12x30)
Optional
6T Heavy duty spiral cutter (1.5x12x30)
Optional
MODEL
A7-40
A7-55
Table area
1090x1400mm
1410x1500mm
Cutterhead motor
20HP
25HP
Cutterhead speed
4200RPM
3600RPM
Feed-in motor
3HP
5HP
Electronic motor
1HP
1HP
Cutterhead diameter
150mm
150mm
Blade quantity
4
4
Feed-in roller
100mmx2
100mmx2
Output roller
100mm
100mm
Feed-in speed
0 ~ 20 M/min
0 ~ 20 M/min
Table roller
100mmx3
100mmx3
Max. planing width
1016mm
1400mm
Range of Planing Thickness
9~200mm
9~200mm
Min.Working Length
305mm
305mm
Dust hood dia.
150mm (6")
150mm (6")
Machine Size(LxWxH)
1410x1563x1485mm
1410x1944x1485mm
Packing Size (LxWxH)
1540x1760x1750mm
1510x2044x1585mm
Net weight
2130kg

2950kg
Gross weight
2500kg
3350kg

Centralized control panel.
Equipped with digital up & down control & frequency conversion feeding-in.


Chain-driven table roller.
4 pcs of belts driven cutterhead.
